® Order Online @ appliedracing. com
Download Our Digital Catalog
# 017417
STAINLESS STEEL
HEADER TRIM RINGS
4-1 / 2” ID
# 017417
$ 18.00
5” ID
# 017418
$ 18.00
# 017404
LS TWO-PIECE MOTOR PLATE 2 piece LS / LSX aluminum motor plate mounts. 062 below deck. Note: LS1 requires lower side bracket sold separately. # 017383 $ 139.95
PROFESSIONAL RADIATOR KIT Includes 19 " all aluminum radiator( no cap provision), and Slimline fan with aluminum shroud.
# 018949 $ 449.95 484.95
LIGHTWEIGHT ALUMINUM STEERING WHEEL 13-Inch diamater, black anodized, 5-bolt design, multiple button mounting provisions. Flat wheel center machined from 6061-T6
# 017445 $ 149.95
BLACK SELF EJECT DZUS
Slot Style
Standard. 500
# 017403
$ 2.75
Standard. 550
# 017404
$ 2.75
Pro Stock. 500
# 017405
$ 3.00
Pro Stock. 550
# 017406
$ 3.00
# 017421
Hex Style Standard. 500
# 017420
$ 3.00
Standard. 550
# 017421
$ 3.00
Pro Stock. 500
# 017422
$ 3.00
Pro Stock. 550
# 017423
$ 3.00
LS MID PLATE Plates are made from. 100 " mild steel, are 30 " wide and can be trimmed to fit any chassis. # 017407 $ 62.50
TIG WELDING REQUIRED
PRO RADIATOR MOUNT KIT All chromoly tubing and brackets. # 019346 $ 49.00
MICRO SWITCH MOUNT PRO Micro Switch Mount Plate Grant Wheel Pro
# 018791 $ 29.95
MICRO SWITCH Micro Switch Button And Cord Small # 019950 $ 39.95
# 017424
# 019855
# 017425
HEX DZUS WRENCH
Stubby 3 / 16”
# 017424
$ 8.95
Standard 3 / 16”
# 017425
$ 8.95
ALUMINUM DZUS RAIL 8 Hole Standard Style. 59-1 / 2”
# 017419 $ 42.50
BLACK ALUMINUM SMASH RIVET 1 / 8” x 5 / 16”. 200-pack
# 017444 $ 16.00 per pack
TUBE STYLE FRONT END TRAVEL LIMITER
TIG WELDING REQUIRED
Made from 4130 Chromoly tubing. Includes tube adapters, rod ends, and hardware.
# 017429 $ 179.95
THREAD-ON TIRE ROD KIT Thread on tie rod kit for 1 / 2 "- 20 thread. Sold as a pair. # 017435 $ 44.95
CARBON / FIBERGLASS WHEEL TUBS Features a one-piece design. 10.5 size 40 " x 25 " # 017446 $ 650.00 Pro size 46 " x 29 " # 019349 $ 850.00
Ships by truck.
LED INTERIOR LIGHT Kit includes mounting bracket and one LED light.
# 017432 $ 18.50
# 019856
STEERING WHEEL EXTENSIONS NHRA-accepted, this billet extension mounts to a 5-hole quick-disconnect hub at one end and a Grant-style wheel at the other. This dual-purpose configuration can be used to either extend the steering wheel location or with steering column modification, to allow more driver space when the steering wheel is removed. 3” Extension # 019855 $ 104.95 5” Extension # 019856 $ 124.95
# 017416 WELDING REQUIRED
EXTREME WEIGHT BAR KITS 15” Bar with End Plates, Sleeves, and Hardware 4” x4” x15”
# 017415 $ 59.95 30” Bar Kit with End Plates, Sleeves, and Hardware 4” x4” x30”
# 017416 $ 74.95
LEAD PUCK 5 lbs, 3-1 / 2” x3-3 / 4” x 1-1 / 2”, antimony alloy resists deforming and is six times harder than plain lead, pre-drilled with 1 / 2” mounting hole. # 019638 $ 16.95
PRO MOD FOOT BOX Chromoly wheelie bar foot box. Uses 1 / 2 " pin for rod end attachment. **** requires two gussets # 017410 ****
# 017409 $ 65.00
WHEELIE BAR FOOT BOX GUSSET Requires two per foot box. **** Chromoly ****
# 017410 $ 4.50
4” PRO WHEELEZE Pro Wheeleze 4 "( 3 / 8 " hole) # 019510 $ 76.50
CAGE KITS Formed for your specific body style and NHRA accepted. Roll cages feature 1- 5 / 8” x. 134 wall mild steel or 1-5 / 8” x. 083 wall 4130 chromoly tubing. All kits include 6” x 6” steel plates.
8-Point 10-Point 12-Point All A. R. T. cages include the dash bar & two rocker bars with no additional upgrade charge.
Roll Cages- Mild Steel
8-Point
# 011468
$ 279.95
10-Point
# 011470
$ 329.95
12-Point
# 011472
$ 369.95
12-Point Plus
# 019713
$ 534.95

Orders Only 800-571-3023 Info & Tech Line( 727) 571-3023 • 24-Hour Fax Line( 727) 572-8698

Roll Cages- 4130 Chromoly
8-Point
# 018520
$ 499.95
10-Point
# 018530
$ 559.95
12-Point
# 018531
$ 619.95
12-Point Plus
# 019714
$ 864.95
