Black powder coated 1” x. 156 CNC-direct threaded Dom
Safety Retainer
Kit
# 018107
16,565 lb. static load capacity heavy duty spherical rod end
CNC-machined 4140 adjuster
4130 solid rod ends and
Grade 8 hardware
1 / 4” housing brackets with adjustable shock mount provision
PRO ADJUSTABLE LADDER BARS A. R. T. ladder bars are 32” long, fully-welded and feature CNC-machined threads. Constructed of 1” OD x. 156 wall DOM tubing, they are powder coated for a long lasting appearance. HD 3 / 4” x 5 / 8” rod ends are used at the front with safety tabs and 3 / 4” x 5 / 8” solid forged rod ends at the rear with a 4140 adjuster located in bottom bar for ease of pinion angle adjustments. Kit also comes with four 1 / 4” mild steel, double shear housing brackets with provisions for adjustable shock mounts and all grade 8 hardware. 32” Pro bar( Pair) w / mild steel rod ends # 018107 $ 499.95 32” Pro bar( Pair) w / chromoly rod ends # 018657 $ 554.95 32” Street Series( Pair) w / polybushed rod ends # 010011 $ 574.95
# 019538
ULTRA PRO SERIES 4-LINK KITS Ultra Pro 4-link kit with mild steel brackets Includes 1-3 / 8” x. 095 chromoly tubing, left hand tube adapters withincorporated hex wrench driver and 1 / 4” mild steel brackets with 5 / 8” holes. Aurora XAM & XAB series C / M rod ends are teflon-lined and feature a 3 / 4” shank and 5 / 8” ball. Includes jam nuts and grade 8 hardware. TIG welding required. # 019538 $ 1014.95
Ultra Pro 4-link kit with chromoly brackets Includes 1-3 / 8” x. 095 chromoly tubing, left hand tube adapters withincorporated hex wrench driver and 1 / 4” chromoly brackets with 1 / 2” holes. Aurora XAM & XAB series C / M rod ends are teflon-lined and feature a 3 / 4” shank and 1 / 2” ball. Includes jam nuts and complete NAS bolt kit. TIG welding required. # 019539 $ 1599.95
# 018201
SPORTSMAN KITS Kit includes choice of mild steel( 5 / 8” or 3 / 4” hole), bolt on brackets, 36” x 3 / 4” OD x. 156 wall CNC threaded DOM tube, high angularity 1 / 2” RH and LH mild steel rod ends with jamnuts and grade 8 hardware. Kit with 5 / 8” mounting holes # 018201 $ 119.95 Kit with 3 / 4” mounting holes # 010025 $ 119.95 Kit with 3 / 4” x 5 / 8” mounting holes # 018535 $ 119.95
WHEELIE BAR PRO KIT Unwelded 84” dual wheel kits feature all 4130 tubing and upper crossbar with unique sleeve feature, which allows adjustment of upper bar length. Features 1-1 / 8” x. 083 upper and lower tubes with 5 / 8” x 1 / 2” aluminum rod ends with jam nuts and Pro 4” roller bearing wheels. TIG welding required. # 018904 $ 854.95
1-1 / 2” gun drilled shaft
# 019982
Billet steel arms
NAS hardware
ANTI-ROLL BAR PRO OUTLAW KIT Kit features 1-1 / 2” diameter 35-spline gun drilled heat-treated 4340 shaft, 6” 1045 billet steel arms, chromoly rod ends, NAS hardware and bearing assembly with mounting brackets. 16-1 / 8” # 019835 $ 734.95 18-1 / 8” # 019982 $ 734.95 20-1 / 8” # 019836 $ 734.95 Custom sizes available
LIGHTWEIGHT ALUMINUM STEERING WHEEL 13-Inch diamater, black anodized, 5-bolt design, multiple button mounting provisions. Flat wheel center machined from 6061-T6 # 017445 $ 149.95
STRUT LOWER CONTROL ARM KIT This kit comes complete with tube adapters, 4130 chromoly tubing, all necessary mounting hardware and 1 / 2” chromoly rod ends. TIG welding required. # 018633 $ 174.95( pair)
STRANGE STRUT PACKAGES Strut packages include:
• Choice of spring rate
• Lower control arm kit with bearings and 1 / 2” chromoly rod ends
• Wheel bearings with seals and hubs with studs
• Steering arms and hardware
• Lightweight brakes do not include hubs, bearings or seals
# 018491
BILLET STRUT CONTROL ARM MOUNT KIT Pre-notched 4130 chromoly, features 360-degree mounting surface, set of four with NAS hardware. TIG welding required. # 019831 $ 299.95
Strut kit with light weight brakes, externally adjustable, 3” stroke, stud mount. Spindle mount wheels only. Single adjustable # 018489 $ 1969.95 Double adjustable # 019774 $ 2399.95
Strut kit with medium duty brakes, externally adjustable, 3” stroke, stud mount Single adjustable # 018491 $ 2119.95 Double adjustable # 019775 $ 2489.95
Strut kit with heavy duty brakes, externally adjustable, 3” stroke, stud mount Single adjustable # 018493 $ 2289.95 Double adjustable # 019776 $ 2659.95
‘ 71-‘ 72 PINTO STYLE These Flaming River units
feature chrome body with polished aluminum housing, 1 / 2” RH SAE tie rod end threads.( overall length 45-1 / 2”) Standard # 008825 $ 259.95 5” Narrowed # 019796 $ 334.95
A. R. T. Rack & Pinion Package: Standard Pinto Rack & Pinion, Rack Mount & Sportsman Weld-on or Thread-on Tie Rod Kit $ 424.95
PROMASTAR SINGLE
ADJUSTABLE SHOCK
# 008985
Aluminum body,
18 adjustment settings.
Extended Recommended Compressed
Height
Ride Height
Height
11 1 / 8”
9 1 / 2”- 10”
# 008982
8 3 / 4”
$ 224.95
16 7 / 8”
14”- 15”
# 008985
11 5 / 8”
$ 224.95
18 3 / 4”
15 1 / 4”- 16 3 / 4”
12 5 / 8”
# 008987
$ 224.95
Special A. R. T. package price: 2 shocks with springs $ 569.95
EXTREME LOWER SHOCK MOUNT KIT CNC-milled from billet aluminum, with a black anodized finish. These mounts will work in conjunction with A. R. T. ladder bar or four-link brackets. Includes NAS hardware( pair). # 017559 $ 189.95
STRANGE SINGLE # 018994 ADJUSTABLE SHOCK Aluminum body, 10 adjustment settings. Extended Recommended Compressed Height Ride Height Height
11 3 / 8” 10”- 10 3 / 8” 8 3 / 4” # 019907 $ 194. 95
17 1 / 8” 13 7 / 8”- 14 1 / 2” 11 5 / 8” # 018994 $ 194.95
19 1 / 8” 15 1 / 4”- 16” 12 5 / 8” # 018608 $ 194.95
Special A. R. T. package price: 2 shocks with springs $ 514.95

Download Our Digital Catalog
