STAGE I KIT // Ladder Bar

• Adjustable Pro 1 ladder bars

• Ladder bar cross member and brackets

• Diagonal link

3627 Stage l ladder bar suspension with 1-3 / 4” round cross member $ 704.95

STAGE II Kit // Ladder Bars with Shocks and Springs

• Adjustable Pro 1 ladder bars

• Ladder bar cross member and brackets

• Diagonal link

• Housing brackets, 1 / 4” thick

• Bracket boxing strips

STAGE III KIT // Ladder Bar Suspension and Subframe

• Adjustable Pro 1 ladder bars

• Mandrel bent 2” x 3” x. 083” or. 120” frame rails

• 2” x 3” ladder bar cross member & brackets

• Diagonal link

• Housing brackets & bracket boxing strips

• Shocks, springs

• Upper shock cross member

• Adjustable lower shock mounts

• Hardware and detailed instructions

3628 Complete ladder bar subframe with Strange all aluminum coil overs( unwelded) $ 1,699.95

Outlaw“ TRIPLE” Adjustable Ladder Bars

3606 Outlaw adjustable ladder bar kit $ 719.95 pr 3606A Outlaw adjustable ladder bar weld-up kit $ 694.95 pr

32” Double Adjustable PRO 1 Ladder Bars

3607 32” Double adjustable Pro 1 ladder bar $ 439.95 pr

Ladder Bar Safety Brackets

Build your own ladder bars or convert your old non-adjusting ladder bars to adjustable by simply adding our adjuster kit. Contains two adjusters with 3 / 4” thread, jam nuts and wrench flats.

3610 Ladder bar adjusters $ 39.95 3612 Ladder bar safety brackets $ 36.95 3636 Front ladder bar bolt kit $ 14.05

• Housing brackets

• Bracket boxing strips

• Hardware and detailed instructions

• Hardware and detailed instructions

• Shocks, springs

• Upper shock cross member

• Lower adjustable shock mounts

3634 Stage II ladder bar suspension with Strange aluminum coil overs $ 1,294.95

The ultimate ladder bar for heavy, high horsepower race cars. 360 degree housing brackets w / integrated shock mounts. Lightweight chromoly construction for strength. Includes all rod ends, hardware and brackets.

An original

Easily installed and tuned for maximum traction, ladder bars can be installed on virtually any car with tremendous results. As with most of our suspension components, our ladder bars carry the Chassis Engineering lifetime limited warranty!

Some kind of front retaining device is required on ladder bars by all sanctioning bodies. Our simple kit will make you legal and give you peace of mind. Kit includes all necessary brackets and hardware to add safety retainers to most ladder bars.

Ladder Bar Adjusters

LOWER ADJUSTER LINK( Standard)

Ladder Bar Crossmembers

Chassis Engineering offers a complete line of ladder bar cross members. The 1 / 4” thick, laser cut, profiled brackets offer 5 holes of adjustment to dial your car in correctly. Round tube cross members are offered in 1-3 / 4” x. 134 mild steel and 1-5 / 8” chromoly. Rectangular cross members are 2” x 3” x. 083 and. 120 wall thickness.

ROD END SAFETY BRACKETS

3718

3819

NOTE: Rear end housing not included. Fabricated 9” and Dana housings available. Available welded or unwelded.

Four-Link Suspension and Subframe Kits

• Mandrel bent 2” X 3” frame rails,. 083” or. 120”

• 1-3 / 4” x. 134” round tube rails

• 1-3 / 4” or 1-5 / 8” x. 083” chromoly rails

• Adjustable lower shock mounts

• Strange Engineering aluminum coil overs with springs

Ideal for high horsepower applications. Constructed from 1 / 4” thick steel plate( chromoly optional) with provisions for lateral support tube for additional strength. Housing brackets are available with or without adjustable shock mount bracket holes. Designed for 5 / 8” rod ends allowing for tighter hole spacing offering more I. C. points. Four-link tubes are chromoly with weld in chromoly tube adapters.

Available for almost any application, these four-link packages are individually matched to take the guesswork out of proper component selection. Pick the four link of your choice – and we’ ll deliver the proper rod ends, locator, shocks and adjustable shock mounts! One great package at one great price!

3512 Four-link kit with 3515 Top Gun four-link( pictured) $ 1,839.95

Mild steel brackets, chromoly upper & lower four-link tubes, chromoly tube adapters, chromoly rod ends, N. A. S. style hardware. Tube size: 1-1 / 4” x 1-3 / 8”

Four-link Tube Kits

• 4130 chromoly rod ends

• Upper shock cross member

• Drive shaft loop

• Top Gun diagonal link

3726 2” x 3” sub-frame( unwelded) with 3515 Top Gun four-link $ 2,249.95 * Chromoly kits available

Top Gun Four-Link Kits

3515 Top Gun four-link kit w / shock mount brackets( less rod ends) $ 629.95

Four-Link Packages

Top Gun XTR Series

3315 $ 1,229.95 3316 All chromoly kit $ 1,599.95

3311 Top Gun four-link bar kit, 1-1 / 4 and 1-3 / 8 bars $ 199.95 3312 XTR chromoly four-link bar kit, 1-3 / 8 and 1-1 / 2 bars $ 279.95 Rod ends must be purchased separately

Browse our entire product line and check out our new lower prices for 2026 @ chassisengineering. com

Toll Free Ordering: 800-327-9402 / Info & Tech: 561-863-2188

NOTE: Rear end housing not included. Fabricated 9” and Dana housings available. Available welded or unwelded. Shown assembled and welded
