Our Eliminator XTR chromoly chassis kit is the latest for Pro Stock and Top Sportsman racing. The XTR chassis kit offers the professional builder and the Do-It-Yourselfer the ability to build a serious chassis for most any drag race application.

This chromoly kit certifies as 25.1G to start and with help from our tech guys it can certify to 25.2 and even 25.3. The XTR comes with integrated funny car cage, fourlink frame brackets plus upper and lower strut mounts. All XTR chassis kits come complete with critical bars pre-bent specifically for your application along with detailed instructions. All bars are shipped a little long for final notching and adjustment for that custom fit.

5710 Eliminator XTR chassis 1-5 / 8” x. 083” chromoly $ 3,999.95

XTR Wheelie bar

The XTR wheelie bars are made with large chromoly tubing, chromoly rod ends and chromoly tube adapters making this kit a perfect choice for Pro Stock, Pro Mod, Top Sportsman and very fast bracket cars.

• 1-1 / 2” X. 065” chromoly upper and lower main tubes

• 1-1 / 4” X. 058” chromoly x-bars and supports

• 5 / 8” X 1 / 2” chromoly rod ends

• Chromoly tube adapters

• Hardware and instructions Wheels not included

3323 XTR Wheelie Bar $ 1,199.95

Top Gun XTR Series

3346 XTR Wishbone Kit

XTR stands for extreme and that is what you get with this new wishbone kit. Big and strong is where it begins.

• Chromoly main tubes – 1-1 / 4” x. 95”

• Pre-welded slip tube for easier and faster assembly

• Precision ground, 1-1 / 4” main slide offers precise control

• Chromoly housing bracket kit

• Nas nuts, bolts and washers

• Chromoly 3 / 4” x 1 / 2” rod ends

• Welding is required( kit is pictured as welded)

Designed for use with four-link suspensions. Modified to work with ladder bars at additional cost of $ 31.00. Need help, call our tech line.

3346 XTR Wishbone kit $ 629.95

Browse our entire product line at chassisengineering. com

The Eliminator X mild steel chassis kit is based on 1-5 / 8” x. 134” mild mteel. It includes the funny car cage just like the moly version. Designed to utilize four-link suspensions and strut front ends, this kit will certifiy down to 7.50. You must go to chromoly if you plan to run 7.49 and quicker. Main hoop, window bars and top hoop are all bent specifically to your dimensions. This offers maximum room and better placement than other kits.

5000 Eliminator X chassis 1-5 / 8” x. 134” mild steel( funny car cage included) $ 3,399.95

As always there are NO crating charges and NO deposits required. Spec sheet is required so call our tech line or see the“ spec sheet” tab on the website for more information and a printable spec sheet.

Mild steel brackets, chromoly upper & lower four-link tubes, chromoly tube adapters, chromoly rod ends, N. A. S. style hardware. Tube size: 1-1 / 4” x 1-3 / 8”

3315 $ 1,229.95 3316 All chromoly kit $ 1,599.95

Fabricated 9” Rear End Housing

Available in mild steel or chromoly from bare housing to complete rear ends. See our website for ordering spec sheet or call one of our techs.

Mild Steel – 3” x. 250” axle tubes standard 4225 56” wide with housing ends not welded $ 894.95 4226 Any width with housing ends welded $ 999.95 4227 Any width with housing ends & back brace welded $ 1099.95 Complete with brackets shown. Call for pricing. Call for chromoly pricing.

Drive Shaft Enclosures

Designed to save the driver from injury in the event of a driveshaft or u-joint failure. Tunnels are made out of. 050” chromoly and fit inside any driveshaft loop with an inside diameter of 6 inches. They are now mandated in Pro-Mod, Pro Stock and Top Sportsman. Sold in pairs.

4015 12” long $ 194.95 pr 4016 18” long $ 215.95 pr 4017 24” long $ 230.95 pr

Drive Shaft Tunnel Kits

4050 12” Tunnel w / 1 loop kit( chromoly) $ 234.95 4051 18” Tunnel w / 2 loop kit( chromoly) $ 304.95 4052 24” Tunnel w / 2 loop kit( chromoly) $ 324.95

( Kits are not welded)

New racer friendlY prices for 2026

Double Frame Rail Kit

The double frame rail kit is designed to give you the material needed to turn your Eliminator XTR Chassis( C / E 5710) into a double rail car. The kit consists of all the chromoly tubing needed for this addition.

5720 Double frame rail kit $ 339.95

Front End Travel Limiters

Travel limiters are one of the easiest tuning devices to install and can make a dramatic difference in the performance of any race car. Limiting front end travel is one of the most common ways to tune out unwanted chassis twist and control excessive wheelstanding. Our travel limiters can be installed on virtually any type of front suspension and are completely adjustable for tuning.

4108 XTR travel limiter – Pro style adjustable slip tube $ 249.95

Outlaw“ TRIPLE” Adjustable Ladder Bars

The ultimate ladder bar for heavy, high horsepower race cars. 360 degree housing brackets with integrated shock mounts. Lightweight chromoly construction for strength. Includes all rod ends, hardware and brackets.

3606 Outlaw adjustable ladder bar kit $ 719.95 pr 3606A Outlaw adjustable ladder bar weld-up kit $ 694.95 pr

Toll Free Ordering: 800-327-9402 / Info & Tech: 561-863-2188
