STAGE III KIT // Ladder Bar Suspension and Subframe

• Adjustable Pro 1 ladder bars

• Mandrel bent 2” x 3” x. 083” or. 120” frame rails

• 2” x 3” ladder bar crossmember & brackets

• Diagonal link

• Housing brackets & bracket boxing strips

• Shocks, springs

• Upper shock cross member

• Adjustable lower shock mounts

• Hardware and detailed instructions

3628 Complete ladder bar subframe with Strange all aluminum coil overs( unwelded) $ 1,714.08

NOTE: Rear end housing not included. Fabricated 9” and Dana housings available. Available welded or unwelded.

STAGE I KIT // Ladder Bar

• Adjustable Pro 1 ladder bars

• Ladder bar crossmember and brackets

• Diagonal link

3627 Stage l ladder bar suspension with 1-3 / 4” round crossmember $ 739.85

Wheel Tubs

Chassis Engineering offers a better selection of aluminum or steel wheel tubs than anyone. These tubs will work with either 2” x 3” or round tube rear frame rail kits. Tubs are shipped in a flat box, saving on freight costs over pre-assmembled or carbon fiber tubs. Half moons are cut and edges rolled, flats are pittsburgh seamed for tight and precise assembly.( pr.)

3684A 23” x 36”-. 040” Aluminum tubs, no beads $ 224.95 3685 28” x 45”-. 040” Aluminum pro tubs, no beads $ 258.45

3686 28” x 40”-. 040” Aluminum intermediate tubs, no beads $ 299.95 3687 Mustang mini tub kit, steel $ 179.95

8045 Front floor kit. 040 Aluminum $ 174.95 8046 Front floor kit. 024 Steel $ 174.95

• Housing brackets

• Bracket boxing strips

• Hardware and detailed instructions

Floor Kits

Available in steel or aluminum, our floor kits are 24” x 60” and can be easily trimmed to fit most applications.

Transmission Tunnel Kits

Our universal and Lenco tranmission tunnel kits can be easily modified to fit most chassis and transmissions. Includes driver and passenger side tunnel halves, driveshaft cover and matching floor pieces.

Sheet Metal Battery Trays

Easy-to-install lightweight battery trays for one or two batteries. Will accommodate virtually any standard automotive battery.

4716 Single sheet metal tray $ 124.95 4717 Dual sheet metal tray $ 144.95

24”

36” long

10” tall

30” long

14” tall

60”

20” wide

Four-Link Packages

Available for almost any application, these four-link packages are individually matched to take the guesswork out of proper component selection. Pick the four-link of your choice – and we’ ll deliver the proper rod ends, locator, shocks and adjustable shock mounts! One great package at one great price!

3512 Four-link kit with 3515 Top Gun four-link( pictured) $ 1,832.62 Add $ 22.00 for panhard bar

Four-link Tube Kits

3311 Top Gun Four-link bar kit, 1-1 / 4 and 1-3 / 8 bars $ 189.95 3312 XTR chromoly four-link bar kit, 1-3 / 8 and 1-1 / 2 bars $ 219.95 Rod ends must be purchased separately

Drive Shaft Tunnel Kits

4050 12” Tunnel w / 1 loop kit( chromoly) $ 234.95 4051 18” Tunnel w / 2 loop kit( chromoly) $ 304.95 4052 24” Tunnel w / 2 loop kit( chromoly) $ 324.95( Kits are not welded)

Rear Floor Kits

All panels are oversized to fit frame rail widths from 20” to 32” and can be easily trimmed for a custom fit. Designed to work with either four-link or ladder bar rear frame kits. These kits contain the necessary pieces to install the rear floor in most cars from the vertical section of the frame rails to the rear bumper.

New racer friendlY prices for 2026

Browse our entire product line at chassisengineering. com

4716

4717

Toll Free Ordering: 800-327-9402 / Info & Tech: 561-863-2188
